FLEXO PRINTER SLOTTER CREASER DIE CUTTER CHAIN FEED
FLEXO PRINTER SLOTTER CREASER DIE CUTTER CHAIN FEED
Machine Configuration
- Chain Feeder Flexo Printer composed with printer, slotter parts, can process 1-10mm cardboard printing creasing slotting etc. procedures.
- Wall board material is casting iron, thickness 40mm, will not be out of shape.
- Spot facing work adopt high precision display processing, center distance of holes can reach ±0.01mm.
- Helical tooth gears on main drive which adopted 45# steel, treated with gear shaving with high precision facility, closed spray lubrication system, put oil before run the machine, can lower down the noise, decrease the abrasion of gears, and prolong the lifetime of gears.
- Adopt the planetary gears phase for the printer slotter driving structure, precise and durable. Phase adjustment adopt taiwan motor and high quality sensor control, precision is ±0.1mm, exact and reliable.
- All bearings use HRB brand.
- Adopt electrical separation, pneumatic locking, pneumatic edition lifting, electric ink distribution, can realize the ink continuous supplying when stop the machine, avoid the ink drying and fading phenomenon when machine stop will affect the printing effect.
- Adopt separation positioning by pneumatic, keep the gears engage position not change when machine separated, the dimensions will not change, improved the production efficiency.
- Adopt crosshead shoe, for the paper 1mm-10mm thickness, the gears meshing gap keep the same, assure the printing precision and prolong the gears using lifetime.
- Ink guiding system adopt high precision anilox roller with independent motor for ink distribution, high quality diaphragm pump supply ink, can adjust the ink volume randomly, improved the ink supplying more average.
- Adopt electrical counter, can control the paper qty exactly, match with warning alarm, can warn workers to keep safe when open or adjust the machine.
- Use CHINT brand electrics.
- The walking rail material is casting, can improve the machine stability.
Quality
Due to high requirements for mechanical quality, raw materials selection, processing, assembly of industrial control over the industry standard, using the new design, quality management system, comprehensive tracking to every detail, delivery to the customer in both hardware and software are a high quality equipment.
Efficiency
Patent type feeding width automatic adjustment device and printing locking device with screw.With 4.0 engineering design of industrialization, both hardware and software are charged with the author’s high efficiency tools.
Service
Based on the industry’s first use of pdm design file management system, complete technical support files, regardless of the long time can still be credible commitment to customers, continuous and efficient after-service for the customer support. 24 hours service with 12 engineers.
Technical specifications :
| CHAIN FEED 4 COLOR PRINTER SLOTTER DIE CUTTER MACHINE | |
|---|---|
| Chain feeder | 1 unit |
| Printer | 2 unit |
| Slotter | 1 unit |
| Die cutter | 1 unit |
| Mechanical speed | 65 pcs/min |
| Normal work speed | 40/50/40-50 pcs/min |
| Max feeding size (mm) | 1450×2450 |
| Min feeding size (mm) | 350×350 |
| Max printing area | 1450×2300 |
Product Details :
| Minimum Order Quantity | Automation Grade | Power (HP) | Speed (RPM) | Roller Diameter (mm) | Condition | Voltage (V) | Weight (kg) | Brand | Size (inch) | Material | Application | Color Printing | Economic Speed | Printing Machine Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 piece | automatic | 7.5 | 60 | 420 | new | 380 | 8000 | assopack | 1200*2600 | paper | corrugated board | 1,2,3,4 | 60 | flexo |
